Touchscreen Signage Celeron
43-Inch Windows Celeron Touchscreen Signage
The 43-inch Infinitus Windows Celeron touchscreen signage offers a large-format all-in-one touchscreen solution with a 3840x2160 4K display and Celeron J6412 processor. Running Windows 11 or Linux, this 43-inch windows all-in-one touchscreen features a capacitive touchscreen with anti-glare technology, ideal for interactive digital signage in retail, corporate, or public settings. With Wi-Fi ax, Bluetooth 5.0, and a durable metal enclosure, this 43-inch windows touchscreen ensures top performance.
Interactive
Touchscreen Features.
Experience the power of ubiquitous technology.
Connect. Expand. Empower. I/O Ports for Seamless data transfer.
Specification
Panel Info
Size | 43" |
Resolution | 3840 x 2160 |
Panel Brightness | 300cd/m² |
Brightness | 250cd/m² with touch Screen |
Contrast | 1000:1 |
Aspect Ratio | 16:9 |
Active Display Area | 941.184 x 529.416mm |
Viewing Angle | 178° |
Touch Data
Touch Tech | G+G 10 point cap touch Anti-Glare Anti-Fingerprint |
Hardness Of Surface | 6H |
Touch method | Finger touch |
Transparency | ≥85% |
Touch Glass Thickness | 4.3mm |
Hardware & OS
CPU | J6412 |
RAM | 8GB, single channel DDR4 2400 MHz (Max 32GB) |
ROM | SATA3.0 256GB SSD |
OS | Window 10 IoT Enterprise LTSC 64 bit, Linux 32 / 64 bit |
CPU Turbo Boos | 2.6GHz |
Base Frequency | 2.0GHz |
CPU Cache | 1.5MB |
BIOS | AMI UEFI BIOS |
GPU Chipset | Intel® UHD Graphics for 10th Gen |
Connectivity
Speaker | 2 x 5W |
Bluetooth | BT 4.0 |
WIFI | IEEE 802.11a/b/n/ac, Wi-Fi compliant |
Ethernet | 100/1000 LAN |
Display Ports | 1 x DP 1.4 |
Connectors | 2 x RJ45 |
Wake on LAN | Yes |
LAN | 2(10/100/1000Mbps) |
USB Ports | 4xUSB 3.2, 3 x USB2.0 header |
Audio | Line-out x 1; Mic-in x 1 |
COM Ports | 5 x RS232 / 1 x RS485 |
GPIO | 8 x GPIO |
General
Color | Metal Enclosure with Black Paint（partly outdoor painted） |
Materials | Black Metal and Aluminium |
Included in Box | INFINITUS Tablet, Power cable |
Operating Environment | Working Temperature: 0-45 degree celsius |
Language | Multi Language |
Sensor | CPU temperature sensor; Voltage sensor; Watchdog; Plug and Start |
Power Management
Power supply unit | Internal |
Power supply | AC100-240V 50/60Hz |
Power usage | TBD |
Sustainability
Regulations | FCC, CE, RoHS support |
REACH SVHC | REACH does not contain SVHC above 0.1%: Lead |
Mounting & Dimensions
VESA | 400 x 400 |
Dimensions ( LxWXH) | 978.5 x 566.7 x 55.2mm |
Weight | 18.5kg |
Box size / each pc(LxWXH) | 1113 x 161 x 690mm |
Master Box size ( LXWXH) | 1113 x 161 x 690mm |
Master Box Weight | 23.7kg |
Pieces/ Carton | 1pc. |
Box/Pallet | 13pcs. |
