Nebula Gen 2
21.5inch Interactive Display
The Nebula Generation 2 21.5-Inch Interactive Display is a large-format touchscreen designed for high-impact applications in environments like quick-service restaurants (QSR) and healthcare kiosks. Boasting a stunning 1920x1080 display with 10-point capacitive touch, it’s driven by a Quad-Core ARM Cortex A55 processor on Android. STAROS provides robust kiosk software for secure kiosk mode, while optional STAR CONTROL enables over-the-air updates and remote configuration. With connectivity options like Wi-Fi, Bluetooth 5.0, and POE-enabled Ethernet, plus support for peripherals like barcode scanners and RFID readers, this freestanding kiosk excels in self-checkout and interactive signage scenarios.
Interactive
Touchscreen Features.
21.5-Inch
Large Format Touchscreen
Interactive Display
Peripherals
Supports barcode scanners, RFID readers, and other accessories for enhanced functionality.
Easy Integration Set Up
Easy integration with connectivity options like 100/1000 LAN PoE, USB, and Type-C ports.
Flip It, Spin It, Table It
Portrait, landscape and table-top orientation
MUSEA:
Digital Signage Software
MUSEA is a cloud-based digital signage software for creating and managing interactive signage content remotely. With drag-and-drop functionality and support for multiple file types, it integrates with Star Control for centralized management across retail, hospitality, and education.
Specifications.
Panel Info
Size | 21.5" |
Resolution | 1920 x 1080 |
Panel Brightness | 450cd/m² |
Brightness | 400cd/m² with touch Screen |
Contrast | 1300:1 |
Aspect Ratio | 16:9 |
Active Display Area | 476.064 x 267.786mm |
Viewing Angle | 89°/89°/89°/89° |
Response time | 14ms |
Touch Data
Touch Tech | G+G 10 point cap touch Anti-glare glass IP65 Front Glass |
Hardness Of Surface | ＞6H |
Touch method | Finger touch 、 Capacitive stylus |
Transparency | ≥86% |
Touch Glass Thickness | 2mm (Not including Sensor thickness) |
Bonded Panel | Optical bonded capacitive touch Panel |
Hardware & OS
CPU | Quad Core ARM Cortex A55@2.0GHz |
RAM | 4GB DDR4 |
ROM | 32GB eMMC Flash |
OS | Android 12 |
Software
STAROS | License Free Kiosk Mode App and Multi App Mode, Auto Lockdown, Browser and Media Mode |
STAR CONTROL(OPTIONAL) | Remote Mobile Device Management |
STARTOOL | Open Source API |
Musea | • Digital Signage Software • Remote Creating and Managing Interactive Signage Content Remotely |
GMS | Support Android 11 GMS |
Video/Image
Video Format | H.265, VP8, RV, WMV, AVS, H.263, Mpeg4, Up to 4K decoding, HTML5, Flash 10 |
Audio Format | MP3, WMA, AAC, etc. |
Image Format | JPEG, BMP, PNG |
Audio/Communication
Speaker | 2x5W |
Bluetooth | BT 5.0 |
Noise Cancellation | X2 with Noise Canceling |
Camera | 2 MP |
Sensor | N/A |
WIFI | 802.11 a/b/g/n/ac 2.4GHz & 5GHz (Three antenna) |
Ethernet | 100/1000 LAN POE |
4G | Optional |
General
Color | Black |
Plastic materials | Plastic ABS |
I/O | RJ45x1, TFslotx1, TYPECx1,USB3.0x1, USB2.0x1, 3.5mm audio x1, DCx1; 1×UART; 2×GPIO; 1×Wiegand; 1×VCC-5V |
Peripheral Connectors | TYPE C x 2 (only for GS module) |
Included in Box | Nebula Tablet, Power Adapter, Power Cable |
POE | Optional IEEE802.3bt(PSE 90W) |
Operating Environment | Working Temperature: 0-45 degree celsius |
Language | Multi Language |
Power Management
Power supply unit | External |
Power supply | DC 12V 5A |
Power usage | N/A |
Sustainability
Regulations | FCC, CE, UKCA , RoHS support |
REACH SVHC | REACH does not contain SVHC above 0.1%: Lead |
Mounting & Dimensions
VESA | 100 x 100 |
Dimensions ( LxWXH) | 515.97 x 36 x 311.97mm |
Weight | 4.9kg (For reference) |
Box size / each pc(LxWXH) | 583 x 115 x 382mm |
Master Box size ( LXWXH) | 604 x 365 x 406mm |
Master Box Weight | 17.5kg (For reference) |
Pieces/ Carton | 3pcs |
Amazing accessories
to complete your perfect kiosk touchscreen computers.
The Touchscreen Computers offers a wide assortment of optional peripherals such as magnetic card swipe, RFID/NFC readers and barcodes that enables flexibility for rigorous use in continuous public use for fitness consoles, system terminals, retail e-catalog, employee access control, corporate check in, restaurant self ordering, hotel check in, etc.
Look into
Nebula Gen 2
Ideal Applications.
Retail
The Touchscreen Computers offers a wide assortment of optional peripherals such as magnetic card swipe, RFID/NFC readers and barcodes that enables flexibility for rigorous use in continuous public use for fitness consoles, system terminals, retail e-catalog, employee access control, corporate check in, restaurant self ordering, hotel check in, etc.
Corporate
Visitor management, meeting room booking, and employee check-in systems.
Hospitality
Guest check-in/check-out, interactive menus, and wayfinding in hotels and restaurants.
Healthcare
Patient check-in, appointment scheduling, and medical information displays.
Education
Interactive learning stations, library check-out systems, and campus information kiosks.
Ticketing kiosks, passenger information displays, and wayfinding in airports and stations.
Transportation
Information kiosks in government offices, museums, and public facilities.
Public Sector
Interactive booths, registration desks, and digital directories.
Events and Exhibitions
